incazelo yomkhiqizo
Imisebenzi eyinhloko yethangi lomfutho we-diaphragm ihlanganisa ukuvikela iphampu yamanzi, ukwehlisa isando samanzi, ukuzinzisa umfutho wamanzi, ukulawula ukushintshashintsha kwengcindezi, ukunciphisa ukusetshenziswa kwamandla, ukunweba impilo yesevisi yesistimu, nokunciphisa umsindo wokusebenza kwemishini. Okulandelayo isingeniso esithile somsebenzi wawo:
Ithangi lomfutho we-diaphragm livikela iphampu yamanzi kanye nepayipi ngokumunca isando samanzi esikhiqizwa lapho iphampu yamanzi iqala futhi ima, inciphisa ukwenzeka kwesando samanzi.
Ithangi lomfutho we-diaphragm lingakwazi ukuzinzisa umfutho wamanzi wesistimu yokuphakelwa kwamanzi. Lapho ingcindezi yesistimu yehla, ingakhulula igesi ecindezelwe ukuze inikeze ukucindezela kwamanzi okuqhubekayo; Uma ingcindezi yesistimu iphezulu kakhulu, ingakwazi ukumunca umfutho wamanzi owedlulele ukuze ivikele amapayipi namaphampu amanzi.
Ithangi lomfutho we-diaphragm lilawula ukucindezela kokusebenza kwamaphampu amanzi nezinye izinto zokusebenza ngokulungisa ukucindezela kwangaphambi kokwehla kwamandla emali kwe-diaphragm, ngaleyo ndlela kusimamise umfutho wamanzi.
Ithangi lomfutho we-diaphragm lingakwazi ukulinganisa ukuguquguquka kwengcindezi ngaphakathi kwesistimu, linciphise umthelela we-hydrodynamic wokugeleza kwamanzi nomsindo wokusebenza, futhi lehlise ukwehluleka kanye namazinga omonakalo wesistimu.
Ithangi lomfutho we-diaphragm linciphisa ukusetshenziswa kwamandla nezindleko zokusebenza ngokunciphisa inani lokuqala nesikhathi sokusebenza kwezinto zokusebenza njengamaphampu amanzi.
Ithangi lomfutho we-diaphragm lihlukanisa umoya ocindezelwe oketshezini olugciniwe ngokusebenzisa i-diaphragm, igcine umfutho wesistimu ozinzile futhi igwema izinkinga ezinjengokuqala nokumiswa kwamaphampu amanzi kanye nokushintshashintsha njalo kwamaphampu ashintshashintshayo.
Ithangi le-diaphragm pressure lingasebenza futhi njengedivayisi yokugcina amanzi. Lapho iphampu yamanzi iyeka ukusebenza, amanzi asethangini lokucindezela kwe-diaphragm asengakwazi ukugcina ukucindezela okuthile, ngaleyo ndlela axazulule inkinga yokucindezela kwamanzi okungazinzile ngokwezinga elithile futhi athuthukise izinga lokuhlinzekwa kwamanzi.
ipharamitha yomkhiqizo
Inombolo yemodeli.(ivolumu:L / Ibha) | Ububanzi D (mm) | Ubude / Ubude H (mm) | I-Inlet A (mm) |
T2/6 | 115 | 195 | G1 |
T5/6 | 150 | 290 | G1 |
T8/6 | 200 | 310 | G1 |
T12/6 | 265 | 290 | G1 |
T19/6 | 265 | 410 | G1 |
T25/6 | 265 | 460 | G1 |
T36/6 | 350 | 540 | G1 |
T50/6 | 350 | 670 | G1 |
T80/6 | 450 | 710 | G1 |
T100/6 | 450 | 790 | G1 |
T150/6 | 450 | 1130 | G1 |
T200/6 | 650 | 950 | G1 |
T300/6 | 650 | 1150 | G1 |
T400/6 | 650 | 1300 | G1 |
T500/6 | 650 | 1650 | G1 |
T600/6 | 700 | 2200 | G1½ |
T800/6 | 800 | 2300 | G1½ |
T1000/6 | 800 | 2650 | G1½ |
T1200/6 | 1000 | 2400 | DN65 |
T1500/6 | 1000 | 2800 | DN65 |
T2000/6 | 1200 | 2700 | DN65 |
T2500/6 | 1200 | 3100 | DN65 |
T3000/6 | 1200 | 3550 | DN65 |
T3500/6 | 1400 | 3200 | DN65 |
Sicela usithinte ukuze uthole amamodeli engeziwe.
